HD100 Square Bathroom Fan - 5W / Brushless Motor
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 78,99 lei | — |
| 3–4 pcs | 75,04 lei | 5% (−3,95 lei/unit) |
| 5–10 pcs | 71,09 lei | 10% (−7,90 lei/unit) |
| 11+ pcs | 67,14 lei | 15% (−11,85 lei/unit) |
Silent square bathroom fan with brushless motor
The HD-125 fan removes moisture and odors from the bathroom without annoying noise, thanks to its brushless motor. Designed for standard 100 mm mounting, it operates efficiently with only 15W power consumption and provides a constant airflow. Ideal for bathrooms, toilets, and dressing rooms in apartments and houses.
What you get with this product
- Extremely quiet operation below 30 dB — won't disturb you in the morning or at night
- Brushless motor — extended lifespan, no maintenance or carbon brush replacement
- IPX2 protection against water splashes — safe in humid bathroom environments
- Low power consumption of 15W — saves on bills, continuous operation without high costs
- Simple installation in standard 100 mm hole — compatible with most existing systems
- Constant airflow of 85 m³/h — effectively removes moisture and odors from spaces up to 8-10 m²
How it works and how to install it
The fan connects to the 220-240V electrical network via a direct connection to a switch or humidity sensor. Installation is done in a 100 mm circular hole in the wall or ceiling, fastened with the included screws through the square outer frame. The brushless motor ensures instant start-up and continuous silent operation, without vibrations. No maintenance required — periodic cleaning of the front grille with a damp cloth is sufficient.
Frequently Asked Questions
How quiet is the fan in operation?
Below 30 dB, the equivalent of a whisper — doesn't disturb sleep and is almost imperceptible during the day.
Can it be installed in the bathroom above the tub or shower?
IPX2 protection allows installation in areas with indirect splashes, not directly under a shower jet. Ideal on the opposite wall or on the ceiling at a minimum distance of 60 cm from the water source.
What is the difference between the 5W motor power and the 15W consumption?
The motor generates 5W of effective mechanical power, and the total power consumption from the network is 15W due to normal internal losses of the electronic components.
Technical specifications
| Model | HD-125 |
| Product Code | Q-14H050 |
| Frame dimensions | 100 x 100 mm |
| Mounting diameter | 100 mm |
| Supply voltage | 220-240V AC, 50Hz |
| Effective motor power | 5W |
| Total power consumption | 15W |
| Airflow | 85 m³/h |
| Noise level | Below 30 dB |
| Motor type | Brushless |
| Protection class | IPX2 |
| Housing material | Moisture-resistant ABS |
| Color | White |
| Conformity standard | GB4343.1-2018, GB4706.1-2005, GB17625.1-2022, GB4706.27-2008 |
Warranty and support
The product benefits from a 24-month warranty according to Romanian legislation, covering manufacturing defects. Right of return within 30 days of delivery. Fast delivery by partner courier throughout Romania.
