Car Fuse with Reset 200A
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 98,99 lei | — |
| 3–4 pcs | 94,04 lei | 5% (−4,95 lei/unit) |
| 5–10 pcs | 89,09 lei | 10% (−9,90 lei/unit) |
| 11+ pcs | 84,14 lei | 15% (−14,85 lei/unit) |
200A Resettable Car Fuse for Electrical Circuit Protection
The 200A resettable car fuse protects electrical installations from overloads and short circuits, preventing damage to expensive equipment. Ideal for automotive, solar, marine systems, or industrial applications, this fuse allows instant restart by simply pressing the reset button, eliminating the need for repeated replacements. Quick installation via screw connections, IP67 protection class against dust and water.
What you get with this product
- Save money — no more buying classic fuses every time it trips; just press the reset button, and the circuit restarts instantly.
- Protects the electrical installation — automatically cuts off current during overloads up to 200A, preventing damage to batteries, inverters, or solar panels.
- Withstands extreme conditions — IP67 rating ensures safe operation at temperatures between -30 and +82 degrees Celsius, resistant to moisture and dust.
- Simple installation without special tools — screw terminals allow direct connection to cables, stable mounting via side holes.
- Maximum versatility — compatible with 12V and 24V DC systems, used in automobiles, trucks, boats, off-grid solar systems, or industrial equipment.
- Visible safety — red reset button clearly indicates when protection has tripped, yellow RESET indicator for quick check.
How it works and how to install
The fuse is installed in series on the main electrical circuit, between the power source and the consumers. The cables are connected to the two golden screw terminals, ensuring proper tightening for stable electrical contact. When the current exceeds 200A or a short circuit occurs, the internal mechanism automatically interrupts the circuit, and the red button pops out. To restart, press the reset button after eliminating the cause of the overload — no component changes, no additional costs.
Frequently Asked Questions
Can I use this fuse for a 24V solar system with a 3000W inverter?
Yes, the fuse works with 12V and 24V DC and supports a nominal current of 200A, which is sufficient for most residential solar systems. Make sure the placement allows easy access to the reset button.
What happens if the fuse trips often?
Frequent tripping indicates a real overload in the circuit — check if the consumers do not exceed the system capacity, the wiring is correctly sized, and there are no short circuits. The fuse does exactly what it should: it protects you.
Is it water and dust resistant for outdoor mounting?
The IP67 protection class ensures complete sealing against dust and resistance to temporary submersion in water. It can be mounted in engine compartments, on boats, or in outdoor solar installations.
Technical Specifications
| Rated Current | 200A |
| Rated Voltage | 12V-24V DC |
| Protection Class | IP67 |
| Operating Temperature | -30°C to +82°C |
| Housing Material | Fireproof ABS + Metal |
| Dimensions | 80 x 50 x 45 mm |
| Number of Terminals | 2 (screw connections) |
| Function | Manual reset via button |
| Applications | Automotive, marine, solar, industrial |
Warranty and support
The product benefits from a 24-month warranty in accordance with Romanian legislation. 30-day return policy from order receipt. Fast courier delivery throughout Romania, secure packaging for optimal transport conditions.
