Set 10 Transparent Terminal Strips 250V-80A
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 122,99 lei | — |
| 3–4 pcs | 116,84 lei | 5% (−6,15 lei/unit) |
| 5–10 pcs | 110,69 lei | 10% (−12,30 lei/unit) |
| 11+ pcs | 104,54 lei | 15% (−18,45 lei/unit) |
Secure Electrical Connections with Professional 250V-80A Transparent Terminal Blocks
The set of 10 transparent terminal blocks ensures fast and secure electrical connections for residential and industrial installations. With an 80A capacity and insulation up to 250V, these terminal strips solve wire connection problems without soldering or special tools. Ideal for electrical panels, lighting installations, and on-site repairs.
What you get with this product
- Secure connections without short circuits — transparent material allows visual inspection of electrical contact
- Quick installation without special tools — integrated clamping screws, terminal connections in under 2 minutes
- Professional 80A capacity — withstands high electrical loads, suitable for motors, industrial sockets, and electrical panels
- Complete set of 10 pieces — enough for a medium electrical panel or multiple connection points
- Savings on installation — replaces expensive individual connectors, reduces work time by up to 40%
- Durability in difficult conditions — fire-retardant plastic resistant to temperatures between -10°C and +90°C
How it works and how to install it
Each terminal block contains independent compartments with clamping screws for securing wires. Strip the wire insulation for 8-10mm, insert it into the corresponding opening, and tighten the screw with a standard flat-head screwdriver. The transparent material allows for visual contact verification. The terminal blocks can be cut to the desired size or connected to each other to form longer strips. No advanced electrician knowledge is required, but it is recommended to disconnect the electrical source before handling.
Frequently Asked Questions
Can I use these terminal blocks for outdoor installations?
They are designed for indoor use or in protected environments. For outdoor use, connection boxes with IP65 protection rating are recommended.
What is the maximum cable cross-section they accept?
The openings accept wires with a cross-section up to 10mm², corresponding to cables of maximum 6mm² solid copper or 10mm² flexible multi-strand.
Can I connect aluminum wires with copper wires?
It is not recommended, as direct aluminum-copper contact generates galvanic corrosion. Use special bimetallic connectors for this purpose.
Technical Specifications
| Maximum Voltage | 250V AC/DC |
| Rated Current | 80A |
| Connector Type | Screw terminal block |
| Terminal Block Size | 35mm length |
| Number of Positions | 12 compartments/block |
| Material | Transparent fire-retardant polycarbonate |
| Set Quantity | 10 pieces |
| Working Temperature | -10°C to +90°C |
| Accepted Cable Cross-Section | Up to 10mm² |
| EAN Code | 0781499707167 |
Warranty and Support
The product benefits from a 24-month warranty according to Romanian legislation for manufacturing defects. Right of return within 30 days of receipt. Fast national courier delivery within 1-3 working days.
