T2 Cable Connector with Lock 300V-10A
Available in stock
Minimum order quantity: 2 pcs
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 5,99 lei | — |
| 3–4 pcs | 5,69 lei | 5% (−0,30 lei/unit) |
| 5–10 pcs | 5,39 lei | 10% (−0,60 lei/unit) |
| 11+ pcs | 5,09 lei | 15% (−0,90 lei/unit) |
T2 Cable Connector with Lock for Safe Electrical Installations
The T2 cable connector with lock ensures stable and secure electrical connections for stranded wires between 0.35-0.75mm, without soldering or special tools. It supports up to 300V and 10A, making it ideal for cable extensions in LED lighting installations, solar panels, or low-voltage electrical systems. The transparent cover and copper contacts guarantee durability and continuous visual inspection.
What you get with this product
- Quick solder-free connection — insert the stranded wires and the automatic lock secures them in under 10 seconds
- Maximum safety at 300V and 10A — flame-retardant copper contacts, IP40 class, resistant to temperatures between -0.35°C and +80°C
- Complete connection visibility — transparent cover allows instant checking of wire positioning
- Compatible with stranded wires between 0.35-0.75mm — connect up to 6 wires simultaneously in one connector
- Installation without an electrician — no special tools required, just insertion and push-lock mechanism
- Compact dimensions 28x16x6mm — easily integrates into junction boxes or tight spaces in installations
How it works and how to install
Lift the transparent tabs of the connector, insert the stripped stranded wires (approx. 5-7mm) into the corresponding holes, then press the tabs until they lock. The internal spring-loaded locking system keeps the wires in permanent contact with the copper blades. You can disconnect at any time by lifting the tabs again. No soldering, electrical tape, or special tools required — the entire process takes less than a minute per connector.
Frequently Asked Questions
Can I use this connector for solid wires or only for stranded wires?
This connector is designed exclusively for stranded (multi-strand) wires. Solid wires will not be properly secured by the locking system and may pull out of the connector.
How difficult is it to remove the wires once they are connected?
Lift the transparent tabs of the connector and gently pull the wires. The system allows for repeated reconnections without damaging the contacts.
Can I connect wires of different diameters in the same connector?
Yes, the connector simultaneously accepts wires between 0.35mm and 0.75mm. Ensure that each wire is fully inserted into its respective hole.
Technical Specifications
| Model | T2 |
| Maximum voltage | 300V DC/AC |
| Maximum current | 10A |
| Compatible wire diameters | 0.35mm / 0.5mm / 0.75mm (stranded) |
| Number of connectable wires | 6 wires simultaneously |
| Operating temperature | -0.35°C to +80°C |
| Protection class | IP40 |
| Dimensions | 28 x 16 x 6 mm |
| Contact material | Copper |
| Housing material | Transparent and black flame-retardant plastic |
Warranty and Support
The product benefits from a 24-month warranty in accordance with current Romanian legislation. Right of return within 30 days of purchase. Fast delivery by partner courier throughout Romania, with telephone confirmation before order dispatch.
