Motor Start Capacitor 30uF/450V AC
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 22,99 lei | — |
| 3–4 pcs | 21,84 lei | 5% (−1,15 lei/unit) |
| 5–10 pcs | 20,69 lei | 10% (−2,30 lei/unit) |
| 11+ pcs | 19,54 lei | 15% (−3,45 lei/unit) |
30uF/450V Motor Start Capacitor for Home and Industrial Appliances
This start capacitor ensures the optimal operation of electric motors in your home or industrial appliances. With a capacity of 30uF and a rated voltage of 450V AC, it guarantees reliable starts and long-term performance for compressors, pumps, fans, and other electric motor equipment.
What you get with this product
- Reliable motor starts — eliminates insufficient torque problems at startup for compressors, pumps, and fans
- Universal compatibility — quickly mounts to any motor with male terminals, without complex interventions
- Tested durability — operates 10,000 hours at 400V or 3,000 hours at 450V according to Class B and C standards
- Guaranteed electrical safety — self-healing polypropylene dielectric that prevents short circuits
- Stable mounting included — screw and nut system for secure mounting on any support or casing
- Extended thermal resistance — operates flawlessly between -40°C and +85°C, ideal for harsh conditions
How it works and how to install it
The capacitor connects to the electric motor's starting circuit, providing the necessary torque for startup. Installation is done by connecting the 4 male terminals to the corresponding motor terminals, according to the appliance's wiring diagram. Mounting on the support is done with the included screw and nut. No special tools are required — any electrician or user with basic knowledge can perform the installation in under 15 minutes.
Frequently Asked Questions
What types of appliances can I use this capacitor with?
It is compatible with motors from air conditioners, refrigerators, fridge-freezers, compressors, water pumps, industrial fans, brush cutters, and other single-phase electric motor equipment.
How do I know if the capacitor is faulty?
Common signs include the motor not starting, unusual noises at startup, or tripping the electrical fuse. Testing with a multimeter confirms the capacitor's condition.
Can I use this capacitor at voltages lower than 450V?
Yes, it works perfectly at 230V or 400V. The rated voltage of 450V is the maximum permissible value, ensuring safety and a longer lifespan.
Technical specifications
| Model | CBB60-P30 |
| Capacitance | 30uF |
| Rated voltage | 450V AC |
| Tolerance | ±5% |
| Contact type | 4 male terminals |
| Frequency | 50-60Hz |
| Operating temperature | -40°C ~ +85°C |
| Lifespan | 10,000h at 400V / 3,000h at 450V |
| Dielectric | Self-healing polypropylene SH |
| Insulation resistance | ≥3000S |
| Casing material | Plastic |
| Flammability class | UL 94 V-2 |
| Quality certification | ISO 9001:2008 |
| EAN | 0781499718767 |
Warranty and support
You benefit from a 2-year warranty in accordance with Romanian legislation for electrical products and a 30-day return policy. Fast courier delivery throughout Romania, with secure packaging for maximum protection during transport.
