Rotary switch 0-3 Positions 2 Cams A241T
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 13,99 lei | — |
| 3–4 pcs | 13,29 lei | 5% (−0,70 lei/unit) |
| 5–10 pcs | 12,59 lei | 10% (−1,40 lei/unit) |
| 11+ pcs | 11,89 lei | 15% (−2,10 lei/unit) |
Professional 0-3 position rotary switch for industrial applications
Rotary switch with 4 contacts and 2 cams, designed for precise control of electrical equipment at voltages up to 400V AC. Ideal for industrial machines, power tools, pumps, and automation, this rotary switch ensures safe operation and long-term durability. Compatible with a wide range of household and industrial applications.
What you get with this product
- Precise 3-position control for easy adjustment of electrical equipment operation
- Supports current up to 16A at 250V, suitable for motors, pumps, and professional tools
- Heat-resistant plastic construction and metal contacts for long-term use in demanding conditions
- Universal compatibility with drills, grinders, water pumps, car automation, and industrial equipment
- Quick installation by direct connection of the 4 contacts, no additional adapters needed
- Compact dimensions allow integration into small spaces in control panels and equipment
How it works and how to install
The switch operates by rotating the central knob which activates the 2 internal cams, switching between 3 fixed positions plus the 0 (off) position. The 4 metal contacts ensure reliable electrical connection. Installation is done by fixing the body into the control panel and connecting the wires to the lug terminals. It supports voltages between 250V and 400V AC, being compatible with both single-phase and three-phase networks. No special tools are required, only a screwdriver for tightening connections.
Frequently asked questions
Can I use this switch for a 2.2kW water pump?
Yes, the switch supports 16A at 250V, sufficient for most domestic and industrial pumps up to 3kW.
Is it compatible with 400V three-phase voltage?
Yes, the switch operates at voltages between 250V and 400V AC, making it suitable for both single-phase and industrial three-phase installations.
What do 2 cams mean and how do they affect operation?
The 2 internal cams control the switching sequence of the 4 contacts, allowing customized control configurations for multi-speed motors or equipment.
Technical specifications
| Model | A241T |
| Number of positions | 0-3 rotary positions |
| Number of contacts | 4 contacts |
| Number of cams | 2 cams |
| Maximum voltage | 250V-400V AC |
| Maximum current | 16A (250V) / 10A (400V) |
| Body material | Heat-resistant plastic |
| Contact material | Coated metal |
| Actuation type | Rotary with position locking |
| Applications | Industrial, household, automotive, power tools |
Warranty and support
The product benefits from a 2-year warranty according to Romanian law. A 30-day return policy allows for returns without justification. Fast delivery by national courier within 1-3 working days.
