220V Mushroom Push Button ON-OFF, Green
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 16,99 lei | — |
| 3–4 pcs | 16,14 lei | 5% (−0,85 lei/unit) |
| 5–10 pcs | 15,29 lei | 10% (−1,70 lei/unit) |
| 11+ pcs | 14,44 lei | 15% (−2,55 lei/unit) |
220V Latching Mushroom Push Button ON-OFF Green
The latching mushroom push button ensures simple and quick control of industrial electric motors and equipment. ON-OFF operation by pressing, ideal for controlling contactors, relays, and electromagnetic starters in control panels. Robust construction with flame-retardant material and silver alloy contacts for long-term reliability.
What you get with this product
- Simple push control: ON on the first press, OFF on the second press, no additional buttons
- Quick installation in a standard 22mm mounting hole, compatible with most industrial electrical panels
- Increased safety with 1NO + 1NC contact and CE certified flame-retardant material, prevents electrical incidents
- Excellent visibility with a 40mm diameter green mushroom cap, easy to identify and operate quickly
- Guaranteed durability with silver alloy contacts, withstands 10A continuous load without degradation
- Universal mounting on industrial equipment, machine tools, conveyor belts, or automated systems
How it works and how to install it
The button is mounted through the 22mm hole in the electrical panel, secured with the included nut. On the first press, the circuit closes and remains active via the latching mechanism. On the next press, the circuit is completely interrupted. Electrical connections are made to the 1NO and 1NC terminals on the back of the button, according to the diagram on the housing. The supply voltage is 220V AC, with a maximum load of 10A.
Frequently Asked Questions
What does the ON-OFF latching function mean?
On the first press, the button remains locked in the ON position and keeps the circuit closed. On the second press, it unlocks and completely cuts off power.
Can I use this button for emergency stop?
No, emergency stop buttons with twist-release are required according to safety standards. This model is for standard ON-OFF control.
Can it be mounted on metal and plastic panels?
Yes, it can be mounted on any standard thickness panel through a 22mm hole, secured with the metal nut.
Technical Specifications
| Rated Voltage | 220V AC |
| Maximum Current | 10A |
| Contact Type | 1NO (normally open) + 1NC (normally closed) |
| Actuation Type | Latching / Self-locking ON-OFF |
| Mounting Hole Diameter | 22mm |
| Mushroom Cap Diameter | 40mm |
| Contact Material | Silver alloy |
| Housing Material | Flame-retardant plastic |
| Cap Color | Green |
| Certification | CE |
| Model | ZB2-BE101 |
Warranty and Support
The product benefits from a 24-month warranty in accordance with Romanian legislation for industrial electrical products. 30-day return policy. Fast delivery via national courier with telephone confirmation.
