Latching Metal Push Button, 22mm, 220V-10A, Blue LED, ElectroAZ
Available in stock
| Quantity | Price per unit | You save |
|---|---|---|
| 1–2 pcs | 44,99 lei | — |
| 3–4 pcs | 42,74 lei | 5% (−2,25 lei/unit) |
| 5–10 pcs | 40,49 lei | 10% (−4,50 lei/unit) |
| 11+ pcs | 38,24 lei | 15% (−6,75 lei/unit) |
22mm Metal Push Button with Latch and Blue LED
The 22mm metal push button with latch is designed for demanding industrial applications where robustness and contact reliability are essential. Powered at 220V and rated for currents up to 10A, it is suitable for automation panels, self-service car washes, vending machines, and HORECA equipment. The aluminum body with IP65 and IK09 protection makes it resistant to both moisture and repeated mechanical actions.
What you get with this product
- Visible status in all lighting conditions — the blue LED ring clearly signals the active status of the button, reducing the risk of operating errors
- Latching function — the button remains in the pressed position without requiring manual holding, useful for continuous start/stop commands
- Resistance to wet and dusty environments — IP65 protection allows installation in areas exposed to water splashes, vapors, or industrial dust
- Vandalism resistance — IK09 rating ensures the mechanical integrity of the button, even in public or semi-public locations
- Flexibility in electrical schematic — the 6 pins (2 for LED, 4 for contact) offer both NO and NC contacts simultaneously, adaptable to various control logics
- Long-lasting connectivity — gold-plated silver alloy contacts minimize contact resistance and resist oxidation during prolonged use
How it works and how to install
The button is mounted in a 22mm hole by screwing with the included removable nut and rubber gasket for sealing. Connection is made via the 6 pins: 2 pins power the blue LED at 220V, and 4 pins form the two switchable NO/NC contacts — choose the type of contact required for your own schematic. The entire installation process does not require special tools, and the markings on the body facilitate pin identification.
Frequently Asked Questions
What is the difference between a latching button and a non-latching button?
A latching button remains in the switched state after pressing and returns to its initial state only with a new press, unlike a momentary button which returns by itself when released.
Can I use this button outdoors, exposed to rain?
Yes, IP65 protection ensures resistance to water jets from any direction, so outdoor installation or in wet areas is possible without additional protection.
Is the blue LED powered separately or together with the contact?
The LED has a separate power supply via 2 dedicated pins at 220V AC, independent of the 4 pins of the electrical contact, which allows for permanent or conditional illumination according to your own schematic.
Technical Specifications
| SKU | EAZ-BP048 |
| Mounting Diameter | 22 mm |
| Thread | M22 |
| Rated Voltage | 220V AC |
| Rated Current | 10A |
| Number of Pins | 6 (2 LED + 4 contact) |
| Contact Type | 1NO + 1NC |
| LED Color | Blue |
| Action Type | Latching |
| Button Profile | Flat |
| Body Material | Aluminum 304 / 316 |
| Contact Material | Gold-plated silver alloy |
| Protection Rating | IP65 / IK09 |
| Actuation Pressure | 500 gf |
| Brand | ElectroAZ |
Warranty and Support
The product benefits from a 2-year legal warranty in accordance with current Romanian legislation. Returns are accepted within 30 days from the delivery date, provided the product has not been modified or damaged. Delivery is fast by courier throughout Romania.
